CSK25 One Way Sprag Bearing 25x52x15mm 85Nm Washing Machine Clutch

Name: CSK25 One Way Sprag Bearing 25x52x15mm 85Nm Washing Machine Clutch
Brand: Changzhou Tianniu Transmission Equipment Co., Ltd
SKU: CSK25
Price: 1.80 USD
Availability: InStock

Ürün Ayrıntıları

Menşe yeri: Jiangsu, Çin

Marka adı: SUMA

Model numarası: CSK25

Ödeme ve Gönderim Koşulları

Min sipariş miktarı: 10

Fiyat: $1.80-2

En İyi Fiyatı Alın

Şimdi iletişime geçin

Özellikler

Açıklama

Özellikler

Vurgulamak:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            CSK25 one way sprag bearing, washing machine clutch bearing 25x52x15mm, 85Nm one way bearing with warranty


Hassas derecelendirme:	P0	Conta Tipi:	Kapalı
Tip:	Sprag	Boyut:	255215mm
Tork:	85 deniz mili	Ağırlık:	0.14kg
Malzeme:	GCR15	İç çap:	25 mm
Dış çap:	52mm	Abartılı hız:	5200 r/min
Tork kapasitesi:	85 deniz mili	Dinamik yük:	10.7KN
Statik yük:	5.46kn	Sürükleme torku:	2ncm
Rulman serisi:	6205

Hassas derecelendirme:	P0
Conta Tipi:	Kapalı
Tip:	Sprag
Boyut:	255215mm
Tork:	85 deniz mili
Ağırlık:	0.14kg
Malzeme:	GCR15
İç çap:	25 mm
Dış çap:	52mm
Abartılı hız:	5200 r/min
Tork kapasitesi:	85 deniz mili
Dinamik yük:	10.7KN
Statik yük:	5.46kn
Sürükleme torku:	2ncm
Rulman serisi:	6205

Açıklama

CSK25 One Way Sprag Bearing 25x52x15mm 85Nm Washing Machine Clutch

CSK25 CSK6205 One Way Sprag Type Bearing Washing Machine Clutch Overrunning Clutch

Product Description

The CSK25 CSK6205 is a sprag type freewheel integrated into a 62 series ball bearing, designed specifically for washing machine clutch applications.

Key Features

Sprag type freewheel integrated with ball bearing (except sizes 8 and 40)
Available in size ranges from CSK 8-40mm to meet various application requirements
Delivered grease lubricated and protected against dust particles larger than 0.3mm
Features "formchromed" sprags for increased overrunning lifetime

Specifications

Product Name	CSK Washing Machine Clutch
Model	CSK25
Material	GCr15
Inner Diameter	25mm
Outer Diameter	52mm
Overrunning Speed	5200r/min
Torque Capacity	85Nm
Weight	0.12kg
Package	Tube / Carton Box / Wooden box
Payment Terms	TT, L/C, D/A, D/P, Western Union
Delivery Time	2-4 days for samples, 7 days for bulk orders

Technical Data

Type	Size (mm)	Bearing Series	Torque (Nm)	Max Speed (r/min)	Outer Diameter (mm)	Width (mm)	Dynamic Load (kN)	Static Load (kN)	Weight (kg)	Drag Torque (Ncm)
CSK(KK)	8*	-	2.5	15000	22	9	3.28	0.86	0.015	0.5

Product Images

Production Process

Frequently Asked Questions

How do you pack the goods?

Small Items: Each in small white box or Roll Pack or Tube pack - in 19x18x9CM carton box - 29*28*19CM carton box - Wooden box / Wooden pallet
Medium Items: 29*28*19cm carton box + Wooden box /Wooden pallet
Heavy Items: Wooden Box / Wooden Pallet

Can I get samples from you?

Yes, we highly encourage customers to request samples for quality verification.

Can you promise to deliver the goods on time?

Small items: In stock
Medium Items: 10-15 Days
Big items: 20-25 Days
